AC & DC Motors

AC & DC Motors

Induction, brushed, brushless and gear motors by frame size.

Also searched as: ac motordc motorbldcgear motorinduction motor

18 parts Best match Lowest price Name Most suppliers

About ac & dc motors

AC and DC motors convert electrical energy into mechanical energy, driving a wide range of industrial and consumer applications. Key types include induction motors, which operate on alternating current and are known for their robustness and efficiency in fixed-speed applications; brushed DC motors, offering simple control and high starting torque; brushless DC (BLDC) motors, providing high efficiency, long life, and precise control without brush wear; and gear motors, which integrate a gearbox with a motor to reduce speed and increase torque. Selection is primarily driven by the required output power, torque, and speed, often specified in Watts, N-m, and RPM, respectively. Frame size, such as NEMA or IEC standards (e.g., NEMA 17, IEC 71), dictates mounting dimensions and often correlates with power output. Voltage and current ratings (e.g., 24VDC, 230VAC) are critical for electrical compatibility. Additional considerations include enclosure ratings (e.g., IP65 for dust and water protection), operating temperature range, and shaft configuration (e.g., D-cut, keyed, or spline). Materials typically involve copper windings, steel laminations, and aluminum or cast iron housings.

How to choose

To select an AC or DC motor, first determine the required mechanical output: torque (N-m) and speed (RPM) for the application. This will dictate the necessary motor power. Second, specify the available electrical supply: AC or DC voltage and frequency. This narrows down the motor type (e.g., induction for AC, brushed/BLDC for DC). Third, consider the operating environment to determine the appropriate ingress protection (IP) rating and temperature range. Finally, evaluate the required mounting configuration, such as NEMA or IEC frame size, and shaft type. If the application demands high torque at low speed, a gear motor should be considered to simplify the mechanical design and improve efficiency.
