Clamps & Clips
Hose, cable, beam, spring and P-clips for holding and routing.
Also searched as: hose clampscable clipsp clipsbeam clampsspring clips
-
1/2 in. 1-Hole Plastic Cable Clamp
Size: 1/2 in.
-
1/2 in. Nylon Rope Light Cable Clamp
Size: 1/2 in.
-
1/4 in. Aluminum EZ Clip
Size: 1/4 in.
-
1/4 in. Plastic Cable Clamp
Color: BlackSize: 1/4 in
-
3.5 Inch Heavy Duty Plastic Spring Clamp
Size: 3.5 Inch
-
3/4 in. Diameter Plastic Cable Clamp
Diameter: 3/4 in.
-
3/8 in. Plastic 1-Hole Cable Clamp
Color: WhiteSize: 1/4 in
-
Adhesive Cord Clip
Color: WhiteSize: 5/8
-
Cable Clip
Color: White
-
-
Cable Clip
Color: BlackSize: 8 mm
-
Coaxial Cable Clamp RG-6
Size: 1/4 in
-
Extended Spring Clip for Pegboard
Hold Range: 1 in to 2 in
-
Galvanized Steel Spring Clip
Height: 5.25 inLength: 6.25 inWidth: 5.5 in
-
Metal Spring Clamps
Jaw Capacity: 1.1 in and 1.6 in
-
Mini Spring Clamp
Clamping Capacity: 0.75 in
-
Multipurpose Cable Clip Holder
Color: Black
-
-
R-Type Cable Clip with Screws
Color: BlackSize: 3/8 in
-
Self-Adhesive Cable Mounting Clip
Slots: 3
-
Spring Clamp
Clamping Strength: 38 poundsSize: 2 in
-
Steel Extended Spring Clips
Hold Range: 0.75 in to 1.25 inProjection: 2.125 in
-
Steel Standard Spring Clip for DuraBoard
Hold Range: 0.25 in to 0.5 inProjection: 1.125 in
-
Zinc Plated Steel Extended Spring Clips for DuraBoard
Height: 2 inHold Range: 0.75 in to 1.25 inProjection: 2.125 inWidth: 4 in
About clamps & clips
Clamps and clips secure, route, and support various components, primarily hoses, cables, and pipes, within mechanical and automation systems. They prevent movement, minimize wear, and ensure organized layouts. Key types include hose clamps (worm drive, band, ear, spring), cable clips (P-clips, saddle clips, adhesive clips), beam clamps, and spring clips. Hose clamps are specified by their clamping range (e.g., 8-16mm, 1/2"-5/8") and material, commonly 304 or 316 stainless steel for corrosion resistance, or galvanized steel for general use. Cable clips are selected based on cable diameter, bundle capacity, and mounting method (screw-mount, adhesive, push-in). P-clips often conform to AS2191 or MS21919 standards, indicating material and cushioning. Beam clamps attach to structural steel without drilling, defined by beam flange thickness and load capacity. Spring clips provide quick, tool-free attachment, typically for light-duty applications, and are characterized by grip range and material. Materials range from various grades of steel (carbon, stainless), aluminum, and plastics (nylon, polypropylene) to specialized elastomers for cushioning or vibration dampening. Finishes include zinc plating, powder coating, and passivation to enhance durability and environmental resistance.
How to choose
When selecting clamps and clips, first identify the item to be secured: hose, cable, pipe, or structural element. For hoses, determine the outer diameter and required clamping force. Consider material compatibility with the fluid and environment (e.g., 316 SS for corrosive applications). For cables, specify the cable diameter or bundle size and the intended routing path. Evaluate mounting options: screw-mount for secure, permanent placement, or adhesive/push-in for lighter duty. For structural attachment, ascertain the beam flange thickness and load requirements. Finally, select the material and finish based on environmental conditions, temperature range, vibration resistance, and any specific industry standards (e.g., aerospace, marine) to ensure optimal performance and longevity.
