Compact Cylinder

This compact pneumatic cylinder has a 40 mm bore and a 20 mm stroke, providing a specific force and travel. With a 16 mm rod diameter and M8 x 1.25 rod thread, it is typically used for short-stroke linear actuation in compact machinery.

Specifications

Bore	40 mm
Overall Height	52 mm
Overall Width	57 mm
Rod Diameter	16 mm
Rod Thread Size	M8 x 1.25
Stroke	20 mm

About pneumatic cylinders

Compact Cylinder is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.

Compare this against other pneumatic cylinders, or search the full index for equivalents from other manufacturers.
