Air Cylinder

GRAINGER APPROVED Aluminum Pneumatic Cylinders

This repairable air cylinder has a 3-1/4 inch bore and 10-inch length, indicating its force and overall size. The magnetic piston allows for position sensing, and it is typically used for robust linear actuation in industrial settings where maintenance and longevity are important.

Specifications

Bore	3.25 inch
Inlet Size	3/8 inch
Stroke	10 inch

About pneumatic cylinders

Air Cylinder is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.

Compare this against other pneumatic cylinders, or search the full index for equivalents from other manufacturers.
