Disc Spring, Belleville

Zoro Select MPN 1UAB5 17-7 PH SS Washers

This Zoro Select Disc Spring, Belleville has a Max Outside Diameter of 2.000 In and a Min Inside Diameter of 1.000 In. It provides a Flat Load of 415 Lbs and a Load of 1148 Lbs with a Deflection @ Load of 0.024 In. This washer is typically used in heavy-duty applications requiring significant spring force and controlled deflection.

Specifications

Deflection @ Load	0.024 In
Flat Load	415 Lbs
Load	1148 Lbs
Max Outside Diameter	2.000 In
Min Inside Diameter	1.000 In
Overall Height	0.145 In
Size	1
Thickness	0.097 In

About washers

Disc Spring, Belleville is listed under Washers — flat, split lock, tooth, belleville and structural washers. Washers are thin, flat plates with a central hole, primarily used to distribute the load of a threaded fastener, prevent loosening, or provide spacing. Flat washers, such as those conforming to ASME B18.21.1 or DIN 125, increase the bearing surface area, reducing the risk of material deformation under the fastener head or nut.
