Worm Gear Speed Reducer

Aluminum Gears

This worm gear speed reducer has a 3.54 inch center distance. With a 20:1 nominal ratio, it provides an output speed of 88 rpm. This component is used to decrease rotational speed and increase torque in mechanical systems.

Specifications

Bore Diameter	1-3/8 inch
Bore Type	Hollow
Frame Size	56C
Input Speed	1750 rpm
Output Speed	88 rpm
Ratio	20:1
Shaft Orientation	Right Angle
Worm Center Distance	3.54 inch

About gears

Worm Gear Speed Reducer is listed under Gears — spur, helical, bevel, worm and internal gears plus racks. Gears transmit rotary motion and torque between shafts, or convert rotary motion into linear motion. This category encompasses a range of gear types, including spur, helical, bevel, worm, and internal gears, as well as racks.
