Worm Gear Speed Reducer

Aluminum Gears

This is a worm gear speed reducer with a 2.48" center distance and a 56C frame size. It has an input speed of 1750 rpm and a nominal ratio of 30:1, resulting in an output speed of 58 rpm with a right-angle shaft orientation. It is typically used to reduce speed and increase torque in mechanical systems.

Specifications

Center Distance	2.48"
Frame Size	56C
Input Speed	1750 rpm
Nominal Ratio	30:1
Output Speed	58 rpm
Shaft Orientation	Right Angle

About gears

Worm Gear Speed Reducer is listed under Gears — spur, helical, bevel, worm and internal gears plus racks. Gears transmit rotary motion and torque between shafts, or convert rotary motion into linear motion. This category encompasses a range of gear types, including spur, helical, bevel, worm, and internal gears, as well as racks.
