Welded Threaded Clevis Cylinder

This is a welded threaded clevis cylinder with a 5-inch bore and 12-inch stroke, providing a column load of 58900 lbs. It has an extended length of 36.25 inches and a retracted length of 24.25 inches, with SAE 12 port size. It is used in heavy-duty applications requiring high force and a clevis mounting.

Specifications

Bore	5"
Column Load	58900 Lbs
Extended Length	36.25"
Pin hole size	1.25"
Port size	SAE 12
Retracted Length	24.25"
Stroke	12"

About hydraulic cylinders

Welded Threaded Clevis Cylinder is listed under Hydraulic Cylinders — tie-rod, welded, telescopic and custom-stroke hydraulic rams. Hydraulic cylinders convert hydraulic power into linear mechanical force and motion. They consist of a cylinder barrel, a piston, and a piston rod.
