Vertical Rotary Table

Vertex MPN TS- Rotary Stages & Tables

This is a Vertical Rotary Table with an adjustable highest point of 260 mm and a 90:1 gear ratio. The 4 slots provide multiple clamping points for workpieces. It is used for precise angular positioning of workpieces in a vertical orientation, often for machining.

Specifications

Adjustable Highest	260 mm
Gear Ratio	90:1
Slots	4

About rotary stages & tables

Vertical Rotary Table is listed under Rotary Stages & Tables — indexing tables, rotary stages, slew rings and turntables. Rotary stages and tables are precision positioning devices that provide controlled angular motion for a wide range of industrial and scientific applications. These components facilitate indexing, precise angular alignment, and continuous rotation of workpieces or sensors.
