Spade Relay Socket

This is a Square D spade relay socket with a screw clamp terminal type. It is rated for 15 A and 300 VAC, accommodating 5 pins. This socket is typically used to house and connect spade-type relays in electrical control systems.

Specifications

Amperage	15 A
Pins	5
Socket Shape	Spade
Terminal Type	Screw Clamp
Voltage	300 VAC

About electrical connectors

Spade Relay Socket is listed under Electrical Connectors — circular, rectangular, terminal, ring and quick-disconnect. Electrical connectors facilitate the establishment of an electrical circuit between two or more components, allowing for the transmission of power or data while enabling modularity and ease of assembly/disassembly. This category encompasses a broad range of form factors, including circular connectors, rectangular connectors, terminal blocks, ring terminals, and quick-disconnect terminals.
