Square Compact Cylinder

This Square Compact Cylinder is a pneumatic actuator with a square body design. The 32 mm bore determines the force output, and the 5 mm stroke indicates a very short linear travel. It is typically used for short-stroke, high-force applications in confined spaces.

Specifications

Bore	32 mm
Stroke	5 mm

About pneumatic cylinders

Square Compact Cylinder is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.

Compare this against other pneumatic cylinders, or search the full index for equivalents from other manufacturers.
