Pneumatic Compact Cylinder

SMC MPN ECQ2A50-75DCM Pneumatic Cylinders

This SMC Pneumatic Compact Cylinder, MPN ECQ2A50-75DCM, is a pneumatic actuator. The 50 mm bore determines the force output, the 20 mm rod diameter indicates its strength, and the 75 mm stroke defines its travel. It is typically used for linear motion in compact automation systems.

Specifications

Bore	50 mm
Rod	20 mm
Stroke	75 mm

About pneumatic cylinders

Pneumatic Compact Cylinder is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.

Compare this against other pneumatic cylinders, or search the full index for equivalents from other manufacturers.
