Short Arm Concealed Hinge

This is a short arm concealed hinge with a 35 mm bore and a 105-degree opening angle. The 35 mm bore is the diameter of the hole required in the door for installation. It is typically used for cabinet doors, allowing the hinge mechanism to be hidden when the door is closed.

Specifications

Bore	35 mm
Opening Angle	105 degrees

About hinges

Short Arm Concealed Hinge is listed under Hinges — butt, piano, concealed, weld-on and heavy-duty industrial hinges. Hinges are mechanical bearings that connect two solid objects, typically allowing only a limited angle of rotation between them. The primary function is to facilitate the opening and closing of doors, panels, or lids.

Compare this against other hinges, or search the full index for equivalents from other manufacturers.
