Right Angle Speed Reducer

MPN HF Style Size 718 Cast Iron Gearboxes & Speed Reducers

This is a Right Angle Speed Reducer, HF Style Size 718, with a 1 inch bore diameter, 16 HP horsepower, 1750 rpm input speed, B5 motor flange, 500 lb overhung load, and 50:1 ratio. The 50:1 ratio reduces input speed by 50 times, and the 16 HP indicates its power capacity. It is typically used in applications requiring significant speed reduction, torque increase, and a right-angle output.

Specifications

Bore Diameter	1"
Horsepower	16 HP
Input Speed	1750 rpm
Motor Flange	B5
Overhung Load	500 lb
Ratio	50:1

About gearboxes & speed reducers

Right Angle Speed Reducer is listed under Gearboxes & Speed Reducers — worm, planetary, helical and right-angle reducers. Gearboxes and speed reducers are mechanical power transmission devices that modify torque and rotational speed between a prime mover and a driven load. They typically consist of a series of gears enclosed within a housing.
