Repairable Welded Hydraulic Cylinder, 5" Bore, 20" Stroke, 3 Stages

This is a repairable welded hydraulic cylinder with a 5-inch bore and a 20-inch stroke, featuring three stages. The multi-stage design allows for a longer stroke in a compact retracted length. It operates at 3000 psi and is used in applications needing high force and extended reach.

Specifications

Bore	5"
Operating Pressure	3000 psi
Port	SAE-10
Stages	3
Stroke Length	20"

About hydraulic cylinders

Repairable Welded Hydraulic Cylinder, 5" Bore, 20" Stroke, 3 Stages is listed under Hydraulic Cylinders — tie-rod, welded, telescopic and custom-stroke hydraulic rams. Hydraulic cylinders convert hydraulic power into linear mechanical force and motion. They consist of a cylinder barrel, a piston, and a piston rod.
