Pneumatic Cylinder

This is a Pneumatic Cylinder with a 100 mm diameter and a 25 mm stroke. The diameter refers to the bore size, influencing force output, while the stroke defines the piston's travel distance. It is typically used for linear actuation in machinery.

Specifications

Diameter	100 mm
Stroke	25 mm

About pneumatic cylinders

Pneumatic Cylinder is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.
