Pneumatic Compact Cylinder

Pneumatic Compact Cylinder

Pneumatic Cylinders

This is a pneumatic compact cylinder. The available bore sizes of 12, 16, 20, 25, and 32 mm define the cylinder's diameter, influencing its force capabilities. It is typically used in applications where space is limited and a compact design is required for linear actuation.

Specifications

Bore12, 16, 20, 25, 32 mm

About pneumatic cylinders

Pneumatic Compact Cylinder is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.

Compare this against other pneumatic cylinders, or search the full index for equivalents from other manufacturers.

Where to buy

1 supplier carry this part. Prices are last-seen and change without notice.
