Acme Screw

Nook MPN 11105 Alloy Steel Ball Screws & Lead Screws

This Acme screw has a diameter of 0.2 inches and a right-hand thread. The diameter affects its load capacity, and the right-hand thread determines the direction of linear motion for a given rotation. It is typically used for converting rotary motion into linear motion.

Specifications

Lash	0.009 in
Overall Length	36 in
Screw Diameter	1 in
Thread Direction	Right Hand
Threads per Inch	5
Travel per Revolution	0.2 in

About ball screws & lead screws

Acme Screw is listed under Ball Screws & Lead Screws — rolled and ground ball screws, acme lead screws and nuts. Ball screws and lead screws convert rotary motion into linear motion, or vice-versa, with high precision and efficiency. Ball screws utilize recirculating ball bearings between the screw shaft and the nut, providing low friction, high efficiency (typically >90%), and minimal backlash.
