Multi-Turn Wave Spring

This is a Multi-Turn Wave Spring with a Heavy Load Duty. Its wave-like coils provide a compact design for heavy load applications, offering significant force in a small axial space. This spring is typically used in situations requiring high force within a constrained assembly.

Specifications

Load Duty	Heavy

About springs

Multi-Turn Wave Spring is listed under Springs — compression, extension, torsion, die and constant-force springs. Springs are mechanical devices designed to store and release elastic energy, typically in response to a compressive, tensile, or torsional force. The primary types include compression springs, which resist compressive loads along their axis; extension springs, which resist tensile loads and often feature hooks or loops at their ends; torsion springs, which apply torque or store rotational energy;
