Linear Guide Shaft Block

This is a linear guide shaft block. The 1.480 inch overall height, 2.000 inch overall width, and 0.500 inch shaft diameter specify its dimensions and the shaft it supports. It is typically used to mount and secure a linear guide shaft.

Specifications

Overall Height	1.480 in
Overall Width	2.000 in
Series	ASB
Shaft Diameter	0.500 in

About linear rails & guides

Linear Guide Shaft Block is listed under Linear Rails & Guides — profile rail, round rail, dovetail and cam-roller guideways. Linear rails and guides provide constrained linear motion for machine axes. The primary types include profile rail, round rail, dovetail slides, and cam-roller guideways.
