Bevel Gears

KHK USA MPN SB1.5-1545 Carbon Steel Gears

This bevel gear has a 10 mm face width and a 12.5 mm hub projection, indicating its tooth contact area and mounting offset. With 15 teeth and a 16 DP pitch diameter, it is designed for specific meshing requirements. It is typically used in systems requiring a 3:1 speed or torque ratio.

Specifications

Face Width	10 mm
Hub Projection	12.5 mm
Number of Teeth	15
Pitch Diameter	16 DP
Ratio	3

About gears

Bevel Gears is listed under Gears — spur, helical, bevel, worm and internal gears plus racks. Gears transmit rotary motion and torque between shafts, or convert rotary motion into linear motion. This category encompasses a range of gear types, including spur, helical, bevel, worm, and internal gears, as well as racks.
