JST SH Series Receptacle Housing

JST (JAPAN SOLDERLESS TERMINALS) Electrical Connectors

This is a JST SH Series receptacle housing with a 1 mm pitch. It is designed for 2 ways, accommodating two contacts. This housing is typically used to create compact wire-to-board connections in electronic applications.

Specifications

Pitch	1 mm
Ways	2

About electrical connectors

JST SH Series Receptacle Housing is listed under Electrical Connectors — circular, rectangular, terminal, ring and quick-disconnect. Electrical connectors facilitate the establishment of an electrical circuit between two or more components, allowing for the transmission of power or data while enabling modularity and ease of assembly/disassembly. This category encompasses a broad range of form factors, including circular connectors, rectangular connectors, terminal blocks, ring terminals, and quick-disconnect terminals.

Compare this against other electrical connectors, or search the full index for equivalents from other manufacturers.
