Hall Encoder - 12bit Quadrature Sensor

Hall Encoder - 12bit Quadrature Sensor

MPN HAE18U5V12A0.5 Encoders & Feedback

This Hall effect encoder is a 12-bit quadrature sensor, meaning it provides 4096 distinct positions per revolution. Its high resolution allows for precise rotational position feedback. It is typically used in applications requiring accurate angular measurement.

Specifications

Bit Resolution12-bit
Output TypeQuadrature
Sensor TypeHall Effect

About encoders & feedback

Hall Encoder - 12bit Quadrature Sensor is listed under Encoders & Feedback — incremental, absolute, rotary and linear encoders plus resolvers. Encoders and feedback devices translate mechanical motion into electrical signals for control and measurement. This category encompasses incremental, absolute, rotary, and linear encoders, alongside resolvers.

Compare this against other encoders & feedback, or search the full index for equivalents from other manufacturers.

Where to buy

1 supplier carry this part. Prices are last-seen and change without notice.
