Fixture Clamp, Compact Toe

This is a compact toe fixture clamp with a holding force of 2000 lb. Its 0.75 in overall width and 5/16-18 thread size with a 1/2 in thread length allow for secure, compact workholding. It is typically used for clamping workpieces in machining operations.

Specifications

Holding Force	2000 lb
Overall Width	0.75 in
Thread Length	1/2 in
Thread Size	5/16-18

About workholding & clamping

Fixture Clamp, Compact Toe is listed under Workholding & Clamping — vises, toe clamps, chucks, magnetic bases and fixture plates. Workholding and clamping components are essential for securing workpieces during machining, assembly, and inspection processes. This category encompasses a range of devices designed to provide rigid, repeatable, and precise workpiece location.

Compare this against other workholding & clamping, or search the full index for equivalents from other manufacturers.
