External C Style Retaining Ring

15-7 Stainless Steel Retaining Rings & Clips

This is an external C-style retaining ring. It has a groove diameter of 0.507" and is designed for a shaft diameter of 9/16". This ring is used to secure components on a shaft, preventing axial displacement.

Specifications

Groove Diameter	0.507"
Shaft Diameter	9/16"

About retaining rings & clips

External C Style Retaining Ring is listed under Retaining Rings & Clips — external, internal, e-clips, spiral and push-on retainers. Retaining rings and clips are critical components for securing assemblies on shafts or within bores, preventing axial movement. They are broadly categorized by their mounting orientation: internal retaining rings fit into grooves within bores, and external retaining rings fit into grooves on shafts.
