Quadrature Encoder

This is a Quadrature Encoder from Durant. It has an overall length of 6.75 inches and a shaft diameter of 0.38 inches (9.5 mm), defining its physical size and mechanical coupling. Quadrature encoders are used to provide position and direction information by generating two phase-shifted pulse trains.

Specifications

Features	Tapped Holes, Military Style Connector
Mount Type	Bracket
Overall Length	9.5 mm
Shaft Diameter	0.38 inches
Type	Quadrature

About encoders & feedback

Quadrature Encoder is listed under Encoders & Feedback — incremental, absolute, rotary and linear encoders plus resolvers. Encoders and feedback devices translate mechanical motion into electrical signals for control and measurement. This category encompasses incremental, absolute, rotary, and linear encoders, alongside resolvers.
