Solid State Relay, Screw, Surface, Triac

Dayton MPN 1EGL9 Relays & Contactors

This is a solid state relay with screw electrical connections and surface mounting. It uses a Triac as the switching component, with an input voltage of 4 to 32V DC and an output voltage range of 48 to 480V AC. It can handle a maximum output current of 40.0 A without a heat sink, and is typically used for switching AC loads with DC control signals.

Specifications

Electrical Connection	Screw
Input Voltage	4 to 32V DC
Maximum Output Current Without Heat Sink	40.0 A
Mounting Style	Surface
Output Voltage Range	48 to 480V AC
Switch Component Type	Triac

About relays & contactors

Solid State Relay, Screw, Surface, Triac is listed under Relays & Contactors — electromechanical, solid-state relays, contactors and sockets. Relays and contactors are electrically operated switches used to control power flow in a circuit. Electromechanical relays utilize an electromagnet to actuate a physical switch, offering galvanic isolation between control and load circuits.
