Curved Spring Washers

304 Stainless Steel Washers

Curved Spring Washers conform to DIN137 A standard and range from M3 to M51 in size. Their curved profile provides a spring action to maintain tension in a bolted joint. They are typically used to compensate for tolerance variations or to provide a light spring force.

Specifications

Size Range	M3 M4 M5 M6 M8 M10-M51
Standard	DIN137 A

About washers

Curved Spring Washers is listed under Washers — flat, split lock, tooth, belleville and structural washers. Washers are thin, flat plates with a central hole, primarily used to distribute the load of a threaded fastener, prevent loosening, or provide spacing. Flat washers, such as those conforming to ASME B18.21.1 or DIN 125, increase the bearing surface area, reducing the risk of material deformation under the fastener head or nut.
