Compact Cylinder - Standard Type

This is a compact cylinder, part number NCDQ2A50-100DCZ, with a 50 mm bore and 100 mm stroke. Its compact design allows for installation in tight spaces. This cylinder is typically used in automation equipment where space efficiency is crucial.

Specifications

Bore	50 mm
Stroke	100 mm

About pneumatic cylinders

Compact Cylinder - Standard Type is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.

Compare this against other pneumatic cylinders, or search the full index for equivalents from other manufacturers.
