Compact Cylinder

This compact pneumatic cylinder features a 20 mm bore diameter and a 15 mm stroke length. The bore diameter indicates the piston size, influencing force output, while the stroke length defines the maximum linear travel. It is commonly used for precise, short-distance actuation in automated systems.

Specifications

Bore Diameter	20 mm
Stroke Length	15 mm

About pneumatic cylinders

Compact Cylinder is listed under Pneumatic Cylinders — single and double-acting, compact, rodless and guided cylinders. Pneumatic cylinders convert compressed air energy into linear motion, providing force and displacement for various industrial automation tasks. They are broadly categorized by their acting mechanism: single-acting cylinders extend with air pressure and retract via spring force, while double-acting cylinders use air pressure for both extension and retraction.
