Coiled Spring Pin

Stainless Steel Pins

This is a coiled spring pin with a nominal and outside diameter of 1/4 inch and a length of 2 inches. The chamfer diameter of 0.243 inches and chamfer length reference of 0.065 inches facilitate insertion. It is typically used for fastening, pivoting, or locating components.

Specifications

Chamfer Diameter	0.243 In.
Chamfer Length Reference	0.065 In.
Length	2 In.
Nominal Diameter	1/4 In.
Outside Diameter	1/4 In.

About pins

Coiled Spring Pin is listed under Pins — dowel, cotter, clevis, roll, spring and taper pins. Pins are unthreaded fasteners used to align, join, or secure components in an assembly. This category encompasses a variety of pin types, each designed for specific applications and load conditions.
