24 Pin Power Circular Connector Male Socket

This is a 24-pin power circular connector male socket. It has a contact diameter of 1.0 mm and is rated for 5 A current with AC operating voltage. It is used for connecting 26-24 AWG wires in power applications.

Specifications

Contact Diameter	1.0 mm
Diameter Range	5.5-7 mm
Operating Voltage	AC
Pins	24
Rated Current	5 A
Wire Gauge	26-24 AWG

About electrical connectors

24 Pin Power Circular Connector Male Socket is listed under Electrical Connectors — circular, rectangular, terminal, ring and quick-disconnect. Electrical connectors facilitate the establishment of an electrical circuit between two or more components, allowing for the transmission of power or data while enabling modularity and ease of assembly/disassembly. This category encompasses a broad range of form factors, including circular connectors, rectangular connectors, terminal blocks, ring terminals, and quick-disconnect terminals.
