CMM Interlocking Plate

This CMM Interlocking Plate is a workholding component measuring 18 inches in both length and width, with a 1/4-20 thread size. It is used to secure parts for inspection on Coordinate Measuring Machines, allowing for precise and repeatable positioning.

Specifications

Hole Pattern	1x1 in
Length	18 in
Thickness	0.5 in
Thread Size	1/4-20
Width	18 in

About workholding & clamping

CMM Interlocking Plate is listed under Workholding & Clamping — vises, toe clamps, chucks, magnetic bases and fixture plates. Workholding and clamping components are essential for securing workpieces during machining, assembly, and inspection processes. This category encompasses a range of devices designed to provide rigid, repeatable, and precise workpiece location.
