Belleville Disc Spring

Belleville Disc Spring

Steel Washers

This Belleville Disc Spring has an ID of 1.25", an OAH of 0.16", and an OD of 2.5". It provides a load of 615.8 lb at a deflection of 0.055". It is typically used in applications requiring high loads in a small space.

Specifications

Deflection0.055"
ID1.25"
Load at Deflection615.8 lb
OAH0.16"
OD2.5"

About washers

Belleville Disc Spring is listed under Washers — flat, split lock, tooth, belleville and structural washers. Washers are thin, flat plates with a central hole, primarily used to distribute the load of a threaded fastener, prevent loosening, or provide spacing. Flat washers, such as those conforming to ASME B18.21.1 or DIN 125, increase the bearing surface area, reducing the risk of material deformation under the fastener head or nut.
