Absolute Encoder

This absolute encoder provides a measuring range of 0 to 2.400 inches with a graduation of 0.00002 to 0.00005 inches, indicating its high precision. It applies a measuring force of 2.5 N and has a 3/8 inch stem diameter. This encoder is used for highly accurate linear position measurement in metrology and precision machinery.

Specifications

Dial Diameter	2.380 inches
Graduation	0.0005 inches/0.01 mm
Output	SPC data
Range	0-0.500 inches

About encoders & feedback

Absolute Encoder is listed under Encoders & Feedback — incremental, absolute, rotary and linear encoders plus resolvers. Encoders and feedback devices translate mechanical motion into electrical signals for control and measurement. This category encompasses incremental, absolute, rotary, and linear encoders, alongside resolvers.
