90° Elbow Adapter

MPN 7202-04-06-NWO-FG Pipe & Pipe Fittings

This is a 90° Elbow Adapter, MPN 7202-04-06-NWO-FG, with a 90° elbow adapter type. End 1 has Male British Standard Pipe Parallel Adjustable O-Ring Boss and Male JIC styles, with 7/16-20 UNF and G - 3/8-19 threads. This adapter changes the direction of fluid flow by 90 degrees and connects components with specified thread types.

Specifications

Adapter Type	90° Elbow
End 1 Style	Male British Standard Pipe Parallel Adjustable O-Ring Boss, Male JIC
End 1 Thread	7/16-20 UNF, G - 3/8-19

About pipe & pipe fittings

90° Elbow Adapter is listed under Pipe & Pipe Fittings — black, galvanized, stainless and pvc pipe with elbows and tees. Pipe and pipe fittings are essential components for fluid and gas conveyance systems across industrial, commercial, and residential applications. Pipes are typically defined by their nominal pipe size (NPS), which approximates the interior diameter, and schedule (SCH), indicating wall thickness and thus pressure rating.
