5/16-18 .027-.150 Large Flanged Rivet Nut

Aluminum Rivets

This is a large flanged rivet nut with a 5/16-18 thread and a 0.027-0.150 inch grip range. The large flange distributes the load over a wider area, and the grip range indicates the total thickness of material it can effectively be installed into. It is used to provide a threaded insert in thin materials.

Specifications

Flange Type	Large Flanged
Grip Range	0.027-0.150 inch
Thread Size	5/16-18

About rivets

5/16-18 .027-.150 Large Flanged Rivet Nut is listed under Rivets — blind, solid, structural and semi-tubular rivets plus setting tools. Rivets are permanent mechanical fasteners used to join two or more components, typically sheets of material. They consist of a smooth cylindrical shaft with a head on one end, which is deformed on the opposite end during installation to create a second head, securing the joint.
