1/4-20 .027-.165 Large Flange Ribbed Nutsert

This is a 1/4-20 Large Flange Ribbed Nutsert. Its ribbed feature provides increased torque-out resistance, and the large flange offers a greater bearing surface. It is used to create a threaded insert in materials with a thickness between 0.027 and 0.165 inches.

Specifications

Feature	Ribbed
Flange Type	Large Flange
Grip Range	0.027-0.165 inch
Thread Size	1/4-20

About rivets

1/4-20 .027-.165 Large Flange Ribbed Nutsert is listed under Rivets — blind, solid, structural and semi-tubular rivets plus setting tools. Rivets are permanent mechanical fasteners used to join two or more components, typically sheets of material. They consist of a smooth cylindrical shaft with a head on one end, which is deformed on the opposite end during installation to create a second head, securing the joint.
